NEC PN-HY501

Sharp PN-HY501 LCD 50" Midrange Large Format Display

• Simply more life-like – the displays come with a wide colour gamut showing every colour with much greater accuracy.
• Operation around the clock – 24/7 with 500 cd/m² brightness.
• Instant plug & go – with the built-in USB MediaPlayer slideshows of 4K Ultra HD photos and videos as well as music can be played, no need to connect a separate PC or other hardware.
• Control made simple – using an integrated LAN/RS-232C interface all your displays can easily be controlled and monitored from a single PC.
• All the flexibility you need – the display can be wall mounted in either landscape or portrait mode as well as face-down on a ceiling or face-up on a table or floor.

• DISPLAY
• Panel Technology TFT with Direct LED backlights
• Active Screen Area (W x H) [mm] 1,095 x 616
• Screen Size [inch/cm] 50 / 125
• Aspect Ratio 16:9
• Pixel Pitch [mm] 0.285 x 0.285
• Brightness [cd/m²] 500
• Contrast Ratio (typ.) 4000:1
• Viewing Angle [°] 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
• Colour Depth [bn] 1.073 (10bit)
• Response Time (typ.) [ms] 8
• Panel Refresh Rate [Hz] 60
• Haze Level [%] Pro (25)
• Supported Orientation Face Down; Face Up 1; Landscape; Portrait
• RESOLUTION
• Native Resolution
• 3840 x 2160
• Supported Resolutions
• 1024 x 768;
• 1280 x 1024;
• 1280 x 720;
• 1280 x 800;
• 1280 x 960;
• 1360 x 768;
• 1400 x 1050;
• 1440 x 900;
• 1680 x 1050;
• 1920 x 1080;
• 3840 x 2160;
• 4096 x 2160;
• 640 x 480;
• 800 x 600;
• 848 x 480
• CONNECTIVITY
• Input Video Analogue 1 x VGA
• Input Video Digital 3 x HDMI (with HDCP)
• Input Audio Analogue 1 x 3,5 mm jack
• Input Audio Digital 3 x HDMI
• Input Control LAN 100Mbit; RS232
• Input Data 1 x USB Medaplayer
• ELECTRICAL
• Power Consumption Eco/max. [W] 110 (max.)
• Power Savings Mode [W] < 0.5; < 1 (Networked Standby)
• Power Management VESA DPMS
• Power Supply 100-240 V AC; 50/60 Hz; internal
• ENVIRONMENTAL CONDITIONS
• Operating Temperature [°C] +0 to +40
• Operating Humidity [%] 20 to 80
• Storage Humidity [%] 10 to 90
• Storage Temperature [°C] -20 to 60
• MECHANICAL
• Dimensions (W x H x D) [mm] 1,128 x 649 x 63.5
• Weight [kg] 15
• Bezel Width [mm] 14.9 (bottom); 14.9 (left and right); 14.9 (top)
• VESA Mounting [mm] 4 holes; 400 x 400 (FDMI); M6
• Packaging Dimensions (W x H x D) [mm] 1,230 x 800 x 142
• Packaging Weight [kg] 18.5
• GREEN FEATURES
• Energy Efficiency Energy consumption: 100 kWh/1000 h; Energy efficiency class: G; LED backlight
• ADDITIONAL FEATURES
• Special Characteristics ASCII Control Commands; CEC Support; Removable Logo; Scheduler; USB Media Player
• Colour Versions Black Front Bezel, Black Back Cabinet
• Safety and Ergonomics CE; EAC; RoHS
• Audio Integrated Speakers (2 x 10 W)
• Shipping Content 2x AAA batteries; CD-ROM (User Guides/Manuals); Display; Logo Sticker; Power Cable; Remote Control; Setup Manual
• Warranty 3 years warranty incl. backlight; on-site service; optional 4. + 5. year warranty extension 2
• Operating Hours 24/7
• External Control ASCII Control Commands; HDMI CEC; Scheduled Timer
